What Are the Advantages of HDPE-coated Prestressed Steel Strand?

As a source supplier deeply involved in the field of prestressed materials, we always focus on "solving engineering corrosion problems and reducing long-term operation and maintenance costs" and concentrate on the research and development and production of prestressed steel strands. Our HDPE-coated prestressed steel strands are an upgrade from traditional steel strands, featuring a high-density

polyethylene (HDPE) coating process. This retains the mechanical advantages of the original substrate while achieving breakthroughs in corrosion resistance and construction compatibility, perfectly matching the demands of high-requirement engineering projects. Its core advantages revolve around "solving challenges" and "enhancing value," as detailed below:

1. Superior Corrosion Resistance

Using imported HDPE raw materials and a three-layer co-extrusion process, the coating achieves maximum sealing, completely isolating moisture, chloride ions, and acid and alkali media. This fundamentally solves the problem of ordinary steel strands easily corroding in coastal, underground, and humid environments, making it particularly suitable for highly corrosive scenarios such as marine engineering and chemical plants.

- Its anti-corrosion effect far exceeds the ordinary galvanized steel strand, and its service life is 3-5 times longer than the uncoated steel strand. It has also passed authoritative salt spray tests and can meet the long-term durability requirements of projects, avoiding rework due to rust in the later stages.

2. Stable Structural Performance

- The coating is processed using an extrusion molding process, which does not damage the steel strand substrate. Its core mechanical properties are completely consistent with the original steel strand. No adjustments to the construction process are required during tensioning; conventional prestressed construction equipment and procedures can be directly used, requiring no additional training or adaptation from the construction team.

- It possesses low relaxation (relaxation rate ≤2.5%), resulting in minimal prestress loss under long-term loads; simultaneously, it boasts high tensile strength (up to 1570MPa or higher), capable of supporting high-strength requirements such as long-span bridges and heavy-load structures.

3. Stronger Construction Adaptability

- The smooth coating surface reduces friction with the ducts during strand threading, facilitating threading over long distances and curved ducts, significantly reducing construction difficulty; furthermore, the coating exhibits excellent toughness (elongation at break ≥300%), making it less prone to breakage due to bending or compression during tensioning, suitable for complex scenarios such as bridge stay cables and pile foundation reinforcement.

- It has a self-bonding property, which forms an isolation layer between the steel strand and the concrete, and can achieve prestress transfer without grouting, directly simplifying the post-tensioning construction process; at the same time, the low friction coefficient (μ=0.1~0.3) can reduce friction loss during the tensioning process and improve the efficiency of prestress application.

4. Less Maintenance Costs

- HDPE coatings exhibit strong resistance to aging and peeling (environmental stress cracking resistance ≥1000h), significantly reducing maintenance and replacement costs due to steel strand corrosion. This makes it particularly suitable for projects with difficult maintenance, such as deeply buried underground structures and cross-sea bridges.

- High tensile strength allows for "lightweight design" through optimized material usage, reducing structural weight and further controlling overall project material costs.

5. Wide Range of Applications

- It is compatible with both "bonded" (grouting after tensioning) and "unbonded" (no grouting required) systems, covering various prestressed applications requiring corrosion protection, including bridges, ports, water conservancy projects, and underground engineering, demonstrating excellent compatibility.

- Typical applications include: marine engineering (cross-sea bridges, port facilities), nuclear power plant containment structures, heavy-duty structures in chemical plants, and precast concrete components requiring rapid construction (railway sleepers, box girders), etc.

As the original manufacturer, we not only offer in-stock supply (standard specifications shipped within 7 days), but also have a dedicated technical team—providing one-on-one service throughout the entire process, from initial project parameter selection to technical guidance during construction and after-sales quality tracking, ensuring your peace of mind when purchasing and using our products.

If you're concerned about the corrosion resistance and durability of your project, or looking to reduce long-term maintenance costs through material optimization, choosing our HDPE coated prestressed steel strands means choosing worry-free engineering support. For specific project quotes or to request free samples, please feel free to contact us anytime; we'll provide you with professional solutions within 24 hours.
