Precision Rolled Threaded Steel
Finish-rolled threaded nut, Flat Hex Nut, also known as finished rolled threaded steel nut, is a high-strength Finish-rolled threaded nut. When in use, the force of the finish-rolled threaded nut is applied by applying pre-tension inside it, and then generating friction resistance on the contact surface between the connected parts to bear the external load. It is usually used in conjunction with a finished rolled threaded steel plate.
ADVANTAGES
Features of Flat Hex Nut:
Flat Hex Nut are widely used in large bridges and slope anchoring projects on highways and high-speed railways.
Flat Hex Nut connection has the advantages of simple construction, good force performance, removable, fatigue resistance, and no loosening under dynamic loads. It is a very promising connection method.
USE
Flat Hex Nut used on finished rolled threaded steel, usually installed in the lower position and often used for fixed ends.
SPECIFICATIONS
Common specifications are divided into 15mm, 20mm, 25mm, 32mm, 36mm, 40mm, and the materials of finished rolled nuts are divided into 45# and 40CR.
Name | Specifications | Materials | Size | Theoretical Weight |
Finish-rolled threaded nut | M15 | 45# | 32*45 | 0.2kg |
Finish-rolled threaded nut | M16 | 45# | 32*45 | 0.2kg |
Finish-rolled threaded nut | M18 | 45# | 32*45 | 0.2kg |
Finish-rolled threaded nut | M20 | 45# | 32*45 | 0.19kg |
Finish-rolled threaded nut | M25 flat nuts | 45# | 50*60 | 0.7kg |
Finish-rolled threaded nut | M25 flat nuts | 40CR | 50*60 | 0.7kg |
Finish-rolled threaded nut | M32 flat nuts | 45# | 60*72 | 1.2kg |
Finish-rolled threaded nut | M36 flat nuts | 40CR | 65*72 | 1.4kg |
Finish-rolled threaded nut | M40 flat nuts | 40CR | 70*100 | 2kg |
Finish-rolled threaded nut | M50 flat nuts | 40CR | 80*110 | 2.8kg |
PACKAGE
box packaging, and carton packaging, or customized packaging.
